Name: Stainless Steel Full Port Ball Valves(V3)
SKU: 67482
Availability: InStock

Description

V3 Valve Specifications
Maximum Operating Pressure: 1/2″ to 2″ — 1000PSI @ 100°F WOG 2 1/2″ to 3″ — 800PSI @ 100°F WOG
Temperature Range: -60 to 450°F
Full Port
End Connections: FNPT
Mounting Options: Padlocking Device and Actuator Mounting Bracket
Material: 316 Stainless Steel
Design Standard ASME: B16.34, GB/T12237 Test & Inspection: API1598, JB/T9092

Main Parts & Materials
No.	Part Name	Material	Quantity
1	Seat	PTFE	2
2	Ball	SS316/CF8M	1
3	Joint Gasket	PTFE	1
4	Cap	SS316	1
5	Body	SS316	1
6	Stem	SS316	1
7	Thrust Washer	PTFE	1
8	Stem Packing	PTFE	1
9	Gland Nut	SS304	1
10	Stem Washer	SS304	1
11	Stem Nut	SS304	1
12	Handle Cover	Plastic	1
13	Handle	SS304	1


V3 Stainless Steel Ball Valve Dimensions
Dimension	d (Nominal Size)	H		W		L
Units	inches	mm	inches	mm	inches	mm	inches
1/4″	0.25	57	2.24	96	3.78	68	2.56
3/8″	0.38	57	2.24	96	3.78	68	2.56
1/2″	0.5	68	2.68	124	4.88	72	2.84
3/4″	0.75	70	2.76	124	4.88	83	3.35
1″	1	80	3.15	142	5.99	90	3.62
1 1/4″	1.25	84	3.31	142	5.99	112	4.33
1 1/2″	1.5	93	3.66	202	7.95	120	4.48
2″	2	100	3.94	202	7.95	147	5.59
2 1/2″	2 1/2	142	5.59	250	9.84	174	6.85
3″	3	155	6.1	250	9.84	193	7.6
4″	4	172	6.77	300	11.81	216	8.5

Additional information

Size	1/4", 3/8", 1/2", 3/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4"
